How Engineers Design for Progressive Collapse Prevention

On May 16, 1968, a small gas explosion in a kitchen on the 18th floor of Ronan Point, a 22-story precast concrete apartment block in London, blew out a load-bearing wall panel. The floors above lost their support and fell, and the impact drove the floors below down with them. One corner of the building peeled away like a stack of dropped plates. A modest local event had produced a structural failure far larger than its cause. That single collapse reshaped how the profession thinks about structural safety.

This article explains what progressive collapse is, why a localized failure can cascade through an entire structure, and the specific methods engineers use to prevent it. We will look at the governing guidance from ASCE 7, the U.S. General Services Administration (GSA), and the Department of Defense Unified Facilities Criteria (UFC), along with the design strategies that turn a vulnerable frame into a robust one. The goal is to make a technical subject understandable without diluting the engineering behind it.

What Progressive Collapse Actually Means

Progressive collapse, sometimes called disproportionate collapse, occurs when the failure of one structural element triggers the failure of adjoining elements, which in turn fail others, until the damage is grossly out of proportion to the original cause. The trigger may be a gas explosion, vehicle impact, blast, construction error, or accidental overload.

The key word is disproportionate. Every building will fail if the load is large enough. Progressive collapse is different because a small, local initiating event produces a global result. The structure lacks the ability to redistribute load around the missing element, so the demand simply migrates to the next member and overwhelms it.

ASCE 7-22 addresses this directly in Section 1.4, General Structural Integrity, which requires that buildings be designed to sustain local damage with the structural system as a whole remaining stable. The commentary to Section 1.4 is one of the most useful starting points for any engineer beginning a robustness study, because it frames collapse resistance as a system property rather than a member-by-member check.

Tie Forces: The Indirect Method

The first line of defense is continuity. The tie force method, also called the indirect method, requires that structural elements be physically and mechanically tied together so the frame can act as a unit. Horizontal ties run through floors in two directions, vertical ties run up the columns and walls, and peripheral ties anchor the edges.

The idea is that if a column is lost, the floor system can develop catenary or membrane action and hang from the surrounding structure rather than dropping. The ties give the load somewhere to go. UFC 4-023-03, Design of Buildings to Resist Progressive Collapse, prescribes minimum tie strengths as a function of floor loading and span, and it is the most prescriptive of the common references on this point.

Tie forces are attractive because they are simple to specify and do not require a separate nonlinear analysis. The limitation is that ties alone do not prove that an alternate load path exists with adequate ductility. For higher-risk buildings, ties are treated as a supplement, not a substitute, for direct analysis.

The Alternate Path Method

The alternate path method (APM) is the workhorse of modern progressive collapse design. The engineer notionally removes a primary vertical element, one column or a defined length of load-bearing wall, and then demonstrates that the remaining structure can bridge over the gap without collapsing. Column removals are studied at the perimeter, at corners, and at interior locations, since each produces a different demand pattern.

Both the GSA Alternate Path Analysis and Design Guidelines and UFC 4-023-03 define this procedure. Three analysis approaches are permitted: linear static, nonlinear static, and nonlinear dynamic, in increasing order of sophistication and accuracy. Because the sudden loss of a column is a dynamic event, static procedures apply load increase factors to approximate the dynamic amplification that the real structure would experience.

Actions are classified as deformation-controlled or force-controlled. Ductile actions such as flexure are allowed to yield and are checked against acceptance criteria expressed through m-factors, while brittle actions such as shear must remain elastic. A beam may be permitted to form plastic hinges and carry load by catenary action, but its connections and shear capacity must not be the weak link.

Enhanced Local Resistance and Risk Tiering

Not every building needs the same level of protection, and the codes scale the requirements to risk. UFC 4-023-03 ties the required level of design to the occupancy category, so a low-occupancy storage building is treated very differently from a primary gathering place or a high-occupancy facility.

For higher categories, the guidance adds enhanced local resistance (ELR), which strengthens perimeter columns and walls so they are less likely to be removed in the first place. This is a recognition that prevention has two halves: stopping a member from failing, and surviving the failure if it happens anyway. ASCE 7 reinforces the same philosophy through its risk category framework in Table 1.5-1, where Risk Category III and IV structures carry the greatest expectation of integrity.

A common failure mode in practice is treating progressive collapse as an afterthought added to a completed design. Robustness is far cheaper and far more effective when the load path, redundancy, and connection ductility are considered from the first framing decisions.

Detailing: Where Robustness Is Won or Lost

Analysis identifies the demand, but detailing delivers the capacity. Catenary and membrane action only develop if connections can accommodate large rotations and tension without fracturing. In reinforced concrete, this means continuous bottom reinforcement through supports and properly developed laps, consistent with the integrity provisions of ACI 318. In steel, it means connections, designed under AISC 360 and its seismic provisions, that retain strength through large deformations.

The lesson from Ronan Point and from later events is consistent. The structures that survive are the ones with continuity, redundancy, and ductile connections. The structures that fail are usually those with brittle details and a single load path. Good detailing is not glamorous, but it is where collapse resistance is actually achieved.

Conclusion

Progressive collapse prevention is the discipline of making sure that a local problem stays local. It rests on three ideas: tie the structure together so load can redistribute, prove an alternate path exists when a key element is lost, and detail connections so they remain ductile under extreme demand. ASCE 7 Section 1.4, the GSA guidelines, and UFC 4-023-03 give engineers a clear and tiered framework for doing this in proportion to a building’s risk.

For owners, developers, and design teams, the most important takeaway is timing. Robustness should be built into the structural concept, not bolted on at the end. If you are planning a project where occupancy, exposure, or risk warrants a collapse resistance review, JMVC Consulting Structural Engineers can assess your structure and recommend a defensible, code-compliant approach. Contact us to discuss your project.
